When you are installing a single 4' x 4' panel, you hang four cables from the building in a 2 foot square configuration. To secure the cable connectors to the building structure, use fasteners by others that are compatible with the building structure. The cables attach below to the individual panel at the four corners of the back frame using cable adjusters. (Note: In an individual panel suspension, you will not use nuts and washers - these are for group hanging purposes.)





















Screw the cable connectors into the threaded holes at the four corners of the metal extrusion and arrange the cable and connectors as shown. The height of a panel can be changed at the Bottom End Cable Adjuster. When a final height is verified and installation is complete, cut off the extra cable wire not needed from where it comes out of the side of the adjuster.



For 4' x 6' panels, the attachment points are the midpoints (not the corners) of each side of the metal extrusion. First, line up the 1/4-20 nuts in the frames to the four mid-point areas of the back frames. Then screw the cable connectors into the 1/4-20 nuts in those locations. This provides the correct support for a 4' x 6' panel.





For 4' x 8' panels, in addition to the four corners, you will need to attach two additional cables to the midpoints of the long sides of the frames. For the midpoint attachments, first line up the 1/4-20 nuts in the frames to the mid-point areas of the frames. Then screw the cable connectors into the 1/4-20 nuts in those places. Along with the corner attachments, this provides the extra support needed for a 4' x 8' panel.



Do not allow any part of the aircraft cable to drop below the panels while adjusting the final panel height. To do so could cause injury to the installer or damage to the edge of a panel.



Galaxy (design and pattern type) in (selected finish and substrate) complete with SoundSorb acoustic backing and Zfix concealed fixing system.


SAMPLE SPECIFICATION
Galaxy Acoustics Shadow Linea GL1S in Snow
White Duratec MR MDF complete with SoundSorb
acoustic backing and Zfix concealed fixing system.



Please contact Arrow Industries for all further technical data including acoustic test reports, fire test report, specification sheets, fixing systems, and samples.
